Cage material: steel or synthetic resin

MOQ: 100pcs

Lead Time: normally 3-5 days

Shipping Port: Guangzhou, Ningbo, Shanghai

Payment: 100% T/T, or 30% T/T in advance ,70% T/T after finished production

The main features of self-aligning ball bearings are:

(1) The outer ring raceway of the self-aligning ball bearing is part of a spherical surface, and the center of curvature is on the bearing axis, so the bearing has the aligning function, and can be automatically adjusted when the shaft and housing are flexing. No additional bearing burden.

(2) It can withstand radial load and appropriate axial load in both directions. But can not withstand the torque load. The contact Angle of this kind of bearing is small, the contact Angle under axial load is almost unchanged, the axial carrying capacity is small, the radial load capacity is large, and it is suitable for heavy load and impact load.

(3) Double-row aligning ball bearings with tightening sleeves and locking nuts can be installed at any position on the optical shaft without the need to locate the shaft shoulder.

Bearing series:

Micro series: 10x, 12x, 13x

General series: 12xx, 13xx, 22xx, 23xx

Application: Aligning ball bearing is suitable for bearing heavy load and impact load, precision instrument, low noise motor, automobile, motorcycle, metallurgy, rolling mill, mining, petroleum, paper making, cement, sugar pressing and other industries and general machinery.
